Gaurav Panchal's Blog: Ubuntu Mail Server (POSTFIX/DOVECOT) with SSL

There are many guides on internet to perform this setup. However, this is my version that includes DKIM, SPF, DMARC and SSL. Considering you have installed fresh Ubuntu, we start from there

POSTFIX

Install postfix

sudo apt-get install postfix

Simply accept the defaults when the installation process asks questions. The configuration will be done in greater detail in the next stage.

sudo dpkg-reconfigure postfix

Insert the following details when asked (replacing server1.example.com with your domain name if you have one):

General type of mail configuration: Internet Site
NONE doesn't appear to be requested in current config
System mail name: example.com
Root and postmaster mail recipient:
Other destinations for mail: server1.example.com, example.com, localhost.example.com, localhost
Force synchronous updates on mail queue?: No
Local networks: 127.0.0.0/8
Yes doesn't appear to be requested in current config
Mailbox size limit (bytes): 0
Local address extension character: +
Internet protocols to use: all

Configure Postfix Inbox

sudo postconf -e 'home_mailbox = Maildir/'
sudo postconf -e 'mailbox_command ='

Configure Postfix SASL

sudo postconf -e 'smtpd_sasl_local_domain ='
sudo postconf -e 'smtpd_sasl_auth_enable = yes'
sudo postconf -e 'smtpd_sasl_security_options = noanonymous'
sudo postconf -e 'broken_sasl_auth_clients = yes'
sudo postconf -e 'smtpd_recipient_restrictions = permit_sasl_authenticated,permit_mynetworks,reject_unauth_destination'
sudo postconf -e 'inet_interfaces = all'

Next edit /etc/postfix/sasl/smtpd.conf and add the following lines:

pwcheck_method: saslauthd
mech_list: plain login

Generate certificates to be used for TLS encryption and/or certificate Authentication:

touch smtpd.key
chmod 600 smtpd.key
openssl genrsa 1024 > smtpd.key
openssl req -new -key smtpd.key -x509 -days 3650 -out smtpd.crt # has prompts
openssl req -new -x509 -extensions v3_ca -keyout cakey.pem -out cacert.pem -days 3650 # has prompts
sudo mv smtpd.key /etc/ssl/private/
sudo mv smtpd.crt /etc/ssl/certs/
sudo mv cakey.pem /etc/ssl/private/
sudo mv cacert.pem /etc/ssl/certs/

Configure Postfix to do TLS encryption for both incoming and outgoing mail:

sudo postconf -e 'smtp_tls_security_level = may'
sudo postconf -e 'smtpd_tls_security_level = may'
sudo postconf -e 'smtpd_tls_auth_only = no'
sudo postconf -e 'smtp_tls_note_starttls_offer = yes'
sudo postconf -e 'smtpd_tls_key_file = /etc/ssl/private/smtpd.key'
sudo postconf -e 'smtpd_tls_cert_file = /etc/ssl/certs/smtpd.crt'
sudo postconf -e 'smtpd_tls_CAfile = /etc/ssl/certs/cacert.pem'
sudo postconf -e 'smtpd_tls_loglevel = 1'
sudo postconf -e 'smtpd_tls_received_header = yes'
sudo postconf -e 'smtpd_tls_session_cache_timeout = 3600s'
sudo postconf -e 'tls_random_source = dev:/dev/urandom'
sudo postconf -e 'myhostname = server1.example.com'

Restart the postfix daemon like this:

sudo /etc/init.d/postfix restart

Install SASL Libraries

sudo apt-get install libsasl2-2 sasl2-bin libsasl2-modules

Configure /etc/default/saslauthd like below

# This needs to be uncommented before saslauthd will be run automatically
START=yes

PWDIR="/var/spool/postfix/var/run/saslauthd"
PARAMS="-m ${PWDIR}"
PIDFILE="${PWDIR}/saslauthd.pid"

# You must specify the authentication mechanisms you wish to use.
# This defaults to "pam" for PAM support, but may also include
# "shadow" or "sasldb", like this:
# MECHANISMS="pam shadow"

MECHANISMS="pam"

# Other options (default: -c)
# See the saslauthd man page for information about these options.
#
# Example for postfix users: "-c -m /var/spool/postfix/var/run/saslauthd"
# Note: See /usr/share/doc/sasl2-bin/README.Debian
#OPTIONS="-c"

#make sure you set the options here otherwise it ignores params above and will not work
OPTIONS="-c -m /var/spool/postfix/var/run/saslauthd"

Configure and start SASLAUTH

sudo dpkg-statoverride --force --update --add root sasl 755 /var/spool/postfix/var/run/saslauthd

sudo ln -s /etc/default/saslauthd /etc/saslauthd

sudo /etc/init.d/saslauthd start

Testing

telnet localhost 25
ehlo localhost

The data should have this

250-STARTTLS
250-AUTH

DOVECOT

Install Dovecot

sudo apt-get install dovecot-common

1. yes
2. localhost
Open /etc/dovecot/conf.d/10-master.conf file and find # Postfix smtp-auth line ( line no:95 ) and add the below lines .

# Postfix smtp-auth
unix_listener /var/spool/postfix/private/auth {
mode = 0660
user = postfix
group = postfix
}

Open /etc/dovecot/conf.d/10-auth.conf file and find (line no:100)

auth_mechanisms = plain

and replace

auth_mechanisms = plain login

Restart Service

sudo service dovecot restart

Install protocols

sudo apt-get install dovecot-imapd dovecot-pop3d

Now configure mailbox. Open /etc/dovecot/conf.d/10-mail.conf file and find (Line no:30 )

mail_location = mbox:~/mail:INBOX=/var/mail/%u

Replace with

mail_location = maildir:~/Maildir

Now change pop3_uidl_format . Open /etc/dovecot/conf.d/20-pop3.conf file and find and uncomment the below line ( Line no : 50 )

pop3_uidl_format = %08Xu%08Xv

Now enable SSL . Open /etc/dovecot/conf.d/10-ssl.conf file and find and uncomment the below line ( Line no : 6 )

ssl = yes

Restart Service

sudo service dovecot restart

Testing

telnet localhost 110

Test all ports

netstat -nl4

Add user

sudo useradd -m webmaster -s /sbin/nologin
sudo passwd webmaster

Test in thunderbird

ClamAV

Install ClamAV

sudo apt-get install clamav clamav-daemon clamav-base amavisd-new clamav-freshclam clamav-docs
sudo apt-get install clamsmtp

Configure Postfix

sudo postconf -e 'content_filter = scan:127.0.0.1:10026'

sudo postconf -e 'receive_override_options = no_address_mappings'

open /etc/postfix/master.cf and Add the codes:

# AV scan filter (used by content_filter)
scan      unix  -       -       n       -       16      smtp
        -o smtp_send_xforward_command=yes
# For injecting mail back into postfix from the filter
127.0.0.1:10025 inet  n -       n       -       16      smtpd
        -o content_filter=
        -o receive_override_options=no_unknown_recipient_checks,no_header_body_checks
        -o smtpd_helo_restrictions=
        -o smtpd_client_restrictions=
        -o smtpd_sender_restrictions=
        -o smtpd_recipient_restrictions=permit_mynetworks,reject
        -o mynetworks_style=host
        -o smtpd_authorized_xforward_hosts=127.0.0.0/8

sudo adduser clamsmtp clamav

Restart Postfix, ClamSMTP, and ClamAV Daemon to make your changes effect:

sudo /etc/init.d/postfix restart
sudo /etc/init.d/clamsmtp restart
sudo /etc/init.d/clamav-daemon restart

Testing

tail /var/log/mail.log

DKIM

Install DKIM sudo apt-get install opendkim opendkim-tools Edit /etc/opendkim.conf as shown below

# Log to syslog
Syslog yes
# Required to use local socket with MTAs that access the socket as a non-
# privileged user (e.g. Postfix)
#UMask 002
# dkim-milter (2.5.2.dfsg-1ubuntu1) hardy:
# Disable new umask option by default (not needed since Ubuntu default
# uses a TCP socket instead of a Unix socket).

# Attempt to become the specified userid before starting operations.
#UserID 105 # 'id postfix' in your shell

# Sign for example.com with key in /etc/mail/dkim.key using
# selector '2007' (e.g. 2007._domainkey.example.com)
Domain ubuntu.ro
KeyFile /etc/mail/dkim.key # See bellow how to generate and set up the key
Selector mail

# Common settings. See dkim-filter.conf(5) for more information.
AutoRestart yes
Background yes
Canonicalization relaxed/relaxed
DNSTimeout 5
Mode sv
SignatureAlgorithm rsa-sha256
SubDomains no
#UseASPDiscard no
#Version rfc4871
X-Header no

#InternalHosts /etc/mail/dkim-InternalHosts.txt
# The contents of /etc/mail/dkim-InternalHosts.txt should be
# 127.0.0.1/8
# 192.168.1.0/24
# other.internal.host.domain.tld
# You need InternalHosts if you are signing e-mails on a gateway mail server
# for each of the computers on your LAN.

###############################################
# Other (less-standard) configuration options #
###############################################
#
# If enabled, log verification stats here
Statistics /var/log/dkim-filter/dkim-stats
#
# KeyList is a file containing tuples of key information. Requires
# KeyFile to be unset. Each line of the file should be of the format:
# sender glob:signing domain:signing key file
# Blank lines and lines beginning with # are ignored. Selector will be
# derived from the key's filename.
#KeyList /etc/dkim-keys.conf
#
# If enabled, will generate verification failure reports for any messages
# that fail signature verification. These will be sent to the r= address
# in the policy record, if any.
#ReportInfo yes
#
# If enabled, will issue a Sendmail QUARANTINE for any messages that fail
# signature verification, allowing them to be inspected later.
#Quarantine yes
#
# If enabled, will check for required headers when processing messages.
# At a minimum, that means From: and Date: will be required. Messages not
# containing the required headers will not be signed or verified, but will
# be passed through
#RequiredHeaders yes

Edit /etc/default/opendkim

# Command-line options specified here will override the contents of
# /etc/dkim-filter.conf. See dkim-filter(8) for a complete list of options.
#DAEMON_OPTS=""
#
# Uncomment to specify an alternate socket
# Note that setting this will override any Socket value in dkim-filter.conf
#SOCKET="local:/var/run/dkim-filter/dkim-filter.sock" # Debian default
#SOCKET="inet:54321" # listen on all interfaces on port 54321
SOCKET="inet:8891@localhost" # Ubuntu default - listen on loopback on port 8891
#SOCKET="inet:12345@192.0.2.1" # listen on 192.0.2.1 on port 12345

edit /etc/postfix/main.cf and add following lines

# DKIM
milter_default_action = accept
milter_protocol = 2
smtpd_milters = inet:localhost:8891
non_smtpd_milters = inet:localhost:8891

Generate Key

opendkim-genkey -t -s mail -d example.com
mkdir /etc/mail
cp mail.private /etc/mail/dkim.key

Copy generated mail.txt value to DNS Host.

Testing

Once configuration above was done, the daemon can be started with:

sudo service opendkim start

If it doesn't start, search the logs for problems and see what it requires more:

grep -i dkim /var/log/mail.log

SPF

For the Python programs, installation is:

sudo apt-get install postfix-policyd-spf-python

Add this section to /etc/postfix/master.cf for the Python script

policy-spf  unix  -       n       n       -       -       spawn
     user=nobody argv=/usr/bin/policyd-spf

Add a line in /etc/postfix/main.cf

policy-spf_time_limit = 3600s

Finally, you need to add the policy service to your smtpd_recipient_restrictions in file /etc/postfix/main.cf

smtpd_recipient_restrictions =
     ...
     permit_sasl_authenticated
     permit_mynetworks
     reject_unauth_destination
     check_policy_service unix:private/policy-spf
     ...

Reload Postfix

sudo /etc/init.d/postfix reload

Testing

tail -f /var/log/mail.log
