Basic Facts of DNS configuration for any domain hosting or DNS Service

Previously, I answered an question on superuser to create a subdomain. So I want to share my knowledge on DNS to everyone who would like to configure their DNS on purchased domain.

DNS means domain naming server, system or service. The most basic server that is used worldwide is BIND (Berkeley Internet Naming Domain). Now basic purpose of DNS server (port 53) is conversion of name to IP. This conversion is important to make computer understand in its own language. Each domain normally has a zone file which is edited by DNS manager system of any registrar or hosting website. The main records in DNS are

HOST A

 This record enables to provide name for IP address. new subdomains can be created using this record.

SUBDOMAIN    CLASS    RECORD TYPE    PROIRITY    IP ADDRESS

 www         IN          A             10        192.168.1.1
  @          IN          A             10        192.168.1.1

MX (mail exchanger)

 It is a mail record required to notify query of mail server of domain. It is not necessary for an sender to only go to an IP of the domain listed in HOST A record for delivery. Therefore mail server of different domains (hosting domain) are possible to use. The priorities and multiple MX record can be set for redundancy. The record with least priority number is the primary mail server

SUBDOMAIN    CLASS    RECORD TYPE    PROIRITY    SERVER NAME

 mail         IN          MX            10        mail.another.com.
  @           IN          MX            10        mail.another.com.

TXT (Text)

 record is additional record, mostly used for domain verification purposes. Example: Google domain verification, SPF, DKIM, DMARC

SUBDOMAIN    CLASS    TTL    RECORD TYPE        VALUE

   @          IN     86400       TXT              "v=spf1 a:mail.example.com -all"

CNAME (Canonical Name)

 This record is used for redirection purposes. The redirection is possible on any domain. Example: redirect to main site or hosting subdomain.

SUBDOMAIN    CLASS    RECORD TYPE        DOMAIN NAME

 www          IN       CNAME              first.mydomain.com.

Note that a fully qualified domain name (FQDN) ends with full stop and sub-domain are without full stop. Some DNS hosting services imply this rule and some don't. So always be careful that full stop(.) is used only after FQDN.

If you dont like to read here is a video to make you understand DNS
